Product Details
＋
These sensors are of the latest generation and measure:
- Atmospheric pressure
- Temperature and humidity
- Light intensity (in LUX)
To help you build projects and store the data collected locally, this shield has a slot for a microSD card (not provided).
There is a ready to use library with examples and methods to read values from the different sensors, that provides an easy and smooth integration path.
Sensors used :
- ST : atmospheric pressure
- ST : temperature and humidity
- VISHAY : Lux of the ambient.
- VISHAY : UltraViolet wavelengths A / B
| ICs |
LPS22HB |
| Input Voltage | 3.3V |
| Operating Voltage | 3.3V |
| Ranges |
Pressure: 260 to 1260 hPa |
| Communication | I2C/Analog |
| Length | 61 mm |
| Width | 25 mm |
| Weight | 32 gr. |
OSH: Schematics
The Arduino MKR ENV Shield is open-source hardware! You can build your own board using the following files:
Sensors used :
- ST : atmospheric pressure
- ST : temperature and humidity
- VISHAY : Lux of the ambient light.
